PE Shrink Film Packaging Machine for Cloth
Features:
1. According to shape and property of package, and the conveyor of machine will be straight line or 90° turning for in-feeding.
2. This machine has including in auto conveyor, push-in device, sealing and shrinking.
3. This machine is easy to be adjusted and operated with any different products. It’s all automatically; do not need any operator that can raise more the production ability.
4. This machine is designed for the film package of rectangular objects which is enable to improve the complication and difficulty in packing process, and also improves the quality of package.
5. This machine is suitable for either independent use or to be utilized in automated production line.
1. According to shape and property of package, and the conveyor of machine will be straight line or 90° turning for in-feeding.
2. This machine has including in auto conveyor, push-in device, sealing and shrinking.
3. This machine is easy to be adjusted and operated with any different products. It’s all automatically; do not need any operator that can raise more the production ability.
4. This machine is designed for the film package of rectangular objects which is enable to improve the complication and difficulty in packing process, and also improves the quality of package.
5. This machine is suitable for either independent use or to be utilized in automated production line.
Specifications
|
Specifications |
||||||
|
Model |
Roll Diameter |
Capacity |
Power |
Packing Mode |
Compressor |
Mechanical Dimension (LxWxH) |
|
WS-8200N |
Ø100~300 mm |
6 Rolls/min |
220V. 3Ø |
Three Sides Seal |
5HP |
8600 x 3300 x 2100 mm |
Applications
1. Using in cloth roll, rubber, plastic roll, curtains, other rectangular box and circular roll material; it has the most effective in packing of cloth roll, rubber and plastic roll.
